Hydraulic Lifting Light Tower
Inquiry NowOverview
| Place of Origin | China |
| Certification | CE |
| Minimum Order Quantity | 1 |
| Packaging Details | Wooden box packaging |
Description
Generator set
Mast
Tire
Outriggers
Power output port
Trailer connection point
Dashboard
LED
365°rotating handle
Emergency stop button
2. Efficient LED lighting system: 4 × 400W LED lights, each can provide 110,000 lumens, providing powerful energy-saving lighting for large work areas.
3. Flexible lighting adjustment: The pole supports manual rotation of up to 330° with a self-locking mechanism and electric lighting Angle adjustment.
4. Reliable diesel engine selection: Can be equipped with Kubota D1105, Yanmar 3TNV76, or Changchai CZ380Q engine, stable performance, reliable power supply.
5. Professional generator system: Support 50/60hz frequency, 230V / 240-120V AC output, class H insulation, IP65 protection, safe operation in harsh environment.
6. Heavy duty trailer design: Trailers are equipped with leaf spring suspension, single axle, 14 "tires, 2" or 50 mm ball tow heads for easy transportation.
7. Long working hours and large fuel tank: The 90-liter tank capacity allows for up to 65 hours of continuous working time, ideal for long night operation.
8. Stable structure, low noise: Equipped with four retractable support legs for stability and working at 72 dB(A) at a height of 7 m, it ensures quieter operation on the job site.
Applications
Specifications
| Technical Parameter — Hydraulic Lifting Light Tower (4HVP1600M) | |||
|---|---|---|---|
| Parameter | Value | Parameter | Value |
| Dimensions & Weight | |||
| Length | 3600mm | Width | 1670mm |
| Height | 2480mm | Fully extended height | 9m |
| Total weight | 1360kg | ||
| Engine Options | |||
| Engine brand | Kubota | Yanmar | Changchai |
| Engine model | D1105 | 3TNV76 | CZ380Q |
| Speed | 1500rpm | 1800rpm | 1500rpm |
| Number of cylinders | 3 | ||
| Engine features | Water-cooled four-stroke | ||
| Combustion method | Indirect injection | ||
| Air intake method | Natural air intake | ||
| Electrical & Generator | |||
| Frequency | 50Hz/60Hz | Rated voltage | 230V AC / 240-120V AC |
| Motor insulation class | Class H | Motor protection class | IP65 |
| Lighting System | |||
| Light type | LED | Luminous flux per lamp | 110000LM |
| Number of lamps & power | 4*400W | ||
| Number of light pole sections | 8 | Light pole lifting | Hydraulic lifting |
| Lamp pole rotation | Maximum manual rotation 330°, self-locking | ||
| Illumination angle adjustment | Electric adjustment | ||
| Chassis & Towing | |||
| Suspension & Brakes | Leaf spring suspension & single axle without brakes | ||
| Traction bar | Telescopically adjustable guide wheel traction bar | ||
| Support legs & quantity | 4 retractable support rods | ||
| Tire size | 14 inch regular tires | Pulling head | 2 inch or 50mm ball pulling head |
| Tail light | Tail reflector | Maximum towing speed | 80 km/h (62 mph) |
| Fuel & Operation | |||
| Fuel tank form | Iron fuel tank | Fuel tank capacity | 90L |
| Continuous working time | 65 hours | Noise level | 72 dB(A) at 7 meters |
Competitive Advantage
Hydraulic lifting lighting tower provides powerful, reliable lighting, simple manual lifting design, easy operation and maintenance. Its 9 m mast provides good coverage for night operations, construction sites, events and emergency works. It has a stable base and adjustable lamps that ensure broad, consistent lighting where you need it most. Compact, durable and efficient, it is ideal for field lighting projects that require reliable and economical lighting.
More than 15 years of manufacturing experience, iso certified production Processes and comprehensive in-house manufacturing capabilities ensure consistent product quality. Every machine Whether after strict testing, stable engine partnership, fast delivery, OEM/ODM custom service, global after-sales support, to ensure that you durable, efficient machine suitable for professional use.
By choosing peak force, you get high quality machines made by trusted factories - world class reliability.
RFQ
1. What is the purpose of the lighting tower?
The hydraulic lifting lighting tower provides powerful and reliable lighting for outdoor work at night such as construction sites, road maintenance, municipal engineering, mining operations, and emergency rescue.
2. What type of lifting system does it use?
Hydraulic lifting masts allow easy lifting without hydraulic or electric systems. Simple operation, low maintenance cost, high reliability.
3. What is the maximum height of the mast?
The mast can be manually lifted to a maximum working height of 9 m to provide extensive lighting coverage for large working areas.
4. What type of lamp to use?
Equipped with high-efficiency LED lamp or metal halide lamp, high brightness, low energy consumption, long life, stable lighting performance.
5. What is the total lighting power?
The total lighting power is 4 × 400w, which provides high intensity lighting and is suitable for high-demand outdoor environments.
6. Is the light adjustable?
Yes. Each lamp head can be rotated and adjusted independently, which can accurately direct the light to the desired position and improve the visibility and work efficiency of the site.
7. What power options are available?
It can be powered by a diesel generator or connected to an external power source, thus making it suitable for both remote and urban applications.
8. Is the lighting tower easy to transport?
Yes. Its compact design and stable structure make it easy to transport, locate and deploy to different workplaces.
9. Is it suitable for outdoor use?
Absolutely. Durable materials and weather-resistant components ensure reliable operation even in harsh outdoor conditions.
10. What security features does it include?
The lighting tower includes a stable base, a secure mast locking mechanism, and a robust structural design to ensure safe operation during lifting and use.
11. What maintenance is required?
The maintenance effort is minimal due to the manual lifting system. Regular inspections include lamp inspection, mast lubrication, fastener tightening, and (if equipped) generator maintenance.
12. Can the product be customized?
Yes. We offer the following customization options: Lighting type and power supply, Generator brand and configuration, Trailer-mounted or skid-mounted base, Color and logo customization.
